Fully Automatic Horizontal Box-Less Molding Machine

XNSW Series Green Sand Automatic Foundry Casting Horizontal Parting Flaskless Molding Machine -This is an automatic molding machine to replace traditional manual hand-molded technique and semi-automatic molding machines.

Quantity: - +

Product Description

XNSW Series Green Sand Automatic Foundry Casting Horizontal Parting Flaskless Molding Machine -This is an automatic molding machine to replace the traditional manual hand molding method. It has a compact structure and high safety performance, easy to operate, cover small floor space, and makes low noise.

Application:
Widely used in castings, machinery parts, auto and motorcycle parts, valves, bearings, cylinder head, flywheel housing, and brake caliper, but also pipe fitting, shaft, and covers, like T joint, elbow, and clamp.
More competitive for those products require an inner sand core.

Main parameter & specification:

Model NumberXNZJ55x45XNZJ60x50XNZJ65x55XNZJ71x61XNZJ71x61H
Size of Sand Mold (mm)550x450600x500650x550710x610

710x610
Modeling Method                                          Sand shooting squeeze molding
Molding Speed sec/mold         32          36          38          38          45
Air pressure MPa         0.6          0.7          0.7         0.7         0.7
Drive Mode                                                 Hydromatic+Pneumatic
Air consumption m3         1.1         1.2         1.2         1.3         1.3
Power supply                                                   AC220-380V DC24v
Weight of Sand Kg         85          130          150          210          320
Motor Power KW        24         28        28         36         36
Maximum Productivity molds/hour         120         100-120       100-120        100-120          90-100
Machine External Dimensions
2900x1830x3000

3740x2150x3140

3740x2150x340

3500x2200x3270

5200x3500x4500
Net weight         7.5T         8.5T         9T         10T         15T


Advantages:
1) Over 12 years of experience in casting equipment.
2) First and most accepted China brand.
3) Most competitive price and quality.
4) Short delivery time.
5) Instant aftersale service online.
6) Import and Export License.
7) OEM.

Pre-sale Service:

1. Providing the most comfortable experience. Welcome clients to visit our head office and factory.

2. Saving money and time. Give clients most professional suggestions and help clients to choose the

most suitable equipment type.

3. Providing the drawings. Help clients to establish the layout of the foundry and installation site.

4. Flexible payment terms.


Medium-sale Service:

1. Ensure the delivery time according to the contract.

2. Help clients to do transportation, safety, and reliability.

3. Ensure can find the first responsible person at any time.
4. Help clients to establish a message system.

After-sale service & Quality assurance:

1) Providing technical advisory services 24 hours, 2 hours of maintenance response time,

2) If the user fails to solve the problem by itself, the on-site service shall be provided for the first time after receiving the notification from the user, except in special cases.

3) The period of quality assurance shall be 12 months from the date of acceptance of the equipment (except for fragile parts and man-made damage).

4) The equipment is guaranteed to be repaired for one year in addition to the causes of improper use and the vulnerable parts of the users. After the warranty period, it will provide lifelong maintenance services.

5) Help clients to debug until the machines work properly

6) Help clients to train their workers until can do it by themselves.

7) Help clients to solve problems when things happen at the first moment.

8) Help clients to maintain the equipment at regular intervals.

9) Warranty 1 year free.
10) Lifetime maintenance.
11) After-sale service:
instant service, by online chatting, or by phone, or by remote services or another way by negotiation.
